Onshape FeatureScript library.

This custom feature creates a bounding box aligned with the selected entities. Useful when finding an entities size or direction.

This custom feature splits the part where the fillet fails. Useful when analyzing the cause of fillet failures.

This custom feature creates an approximated surface by sampling the selected faces. Useful when merging faces into one face.

This custom feature booleans composite parts. Useful when working with composite parts.

Boolean multiple groups of parts in one feature

Capture faces + flood spread, for exporting then re-import performance boost

A freehand chisel tool for removing material

Compare parts and view the compare data

Create composites using dynamic selections

Creates a constrained surface from a query variable.

This custom feature creates a convex polyhedron from vertices. Useful when you need a convex polyhedron.

This custom feature generates a curve from a calculated sketch path. Useful when calculating paths.

A custom import tool in case you need to re-import

Frames cutlist but with part property and rounding options

Convert decimals to fractions

Deform a part or surface along a path (twist, curve, scale)

Creates a sequence of numbers in a pattern or the order you select

Creates a portal to another dimension

A freehand drawing tool.

Adds drawer slides to drawers

Fills difficult to reach voids within a part

This custom feature creates a grid via composite curves. Useful when sketching grid style.

Adds hinges to doors

Overlays images onto your part without manual sketches

This custom feature imprints a pre-defined sketch onto a part. Useful when tagging parts with logos, words, or icons. ㅤ ㅤ ㅤ

A place for users to input data, really useful for mobile

This custom feature creates a 3D part by intersecting flat views from sketches. Useful when creating parts based on drawings. ㅤ ㅤ ㅤ

Extrude with an offset around the extruded face

ㅤ ㅤ ㅤ

This custom feature allows suppression via logical expressions, binary, or even feature list dependencies.

Yet another measuring tool, I don't really use this one

ㅤ ㅤ ㅤ

Sign aware measureing from a mate coordinate system

This custom feature creates variables from measured values. Useful when dimensioning entities.

Add or remove parts from an existing composite part

Automated fillets with solving iterations

This custom feature places mate connectors with advanced placement. Useful when mating to difficult locations.

Moves all of the adjacent faces inward or outward

This custom feature offsets a curve in 3D. Useful when getting offset curves that reference a face.

This custom feature sweeps a profile along multiple paths. Useful when creating multiple sweeps.

Creates a series of zero tancency lofted surfaces between edges

A simple polyline tool for creating segmented polylines in 3D

This custom feature sets the properties of your parts. Useful for dynamically controlling part properties.

Creates a query feature pattern applied by proximity to target

Creates a reflected ceiling plan by slicing and mirroring

Revolves adjacent sketch faces as seperate bodies

This custom feature creates rolling transform. Useful when rolling entities along a path.

Route up to entities while maintaining references

Split the selected parts, like a section view

This custom feature creates a saved selection by setting an attribute for the query finder to use downstream. Useful for automating entity selections.

Quickly insert primative shapes

Adds shelves and holes between two parts

Creates bulk single edge variable fillets.

Creates a spiral part

Splits square empty "frame" like parts (DEPRICATED)

Patterns a split along a part

Serialize and deserialize strings for passing data through non string parameters

Creates a fake mate connector that can be referenced

Blends two faces along an edge

Sweeps adjacent sketch faces as separate bodies

This custom feature creates an Onshape table based on a CSV or manual entry. Useful when using spreadsheets.

Inserts text on a part

This custom feature creates a texture by patterning parts along a face or surface. Useful when creating textures on a surface.

This custom feature the distance between faces. Useful when visually inspecting distances between faces.

Offsets and extrudes a given shape forming a neat shape

This custom feature creates patterned instances via transform. Useful when the pattern is not linear or circular.

For checking if conditions are met

Converts a value with units to a readable string

Like the variable feature, but with rounding

This custom feature changes the volume or surface area of a part until it reaches the target value. Useful when finding a specific volume or surface area. ㅤ ㅤ ㅤ

This custom feature deletes parts based on the selected zone body. Useful when deleting patterned parts from a specific area. ㅤ ㅤ ㅤ

This custom feature copies the flat pattern of a sheet metal part. Useful when working with sheet metal parts.

This custom feature deletes any type of body. Useful when the native Delete feature can't handle it.

This custom feature creates a variable pitch helix. Useful when creating complex helix curves.
